2015 Year

AUTOHANN: 15 Pres Ave Cor Don Rufino St. Tahanan, Bf Homes, Paranaque City
Contact Numbers: 8.4.2.3.2.9.6 / 8.4.2.0.3.2.6 / 0.9.3.0.8.7.0.2.0.0.1 / 0.9.0.6.1.8.4.3.8.4.6



Engine: 2-stroke single cylinder
Engine capacity: PX 125: 123 cc PX 150: 150 cc
Bore: PX 125: 52.5 mm PX 150: 57.8 mm
Stroke: 57 mm
Ignition: CDI electronic ignition
Starter: Electrical and kick starter
Lubrication: Automatic mixer
Cooling system: Forced air
Gearbox: Four speed manual
Load bearing structure: Steel body
Front suspension: Link arm with coil spring and dual action hydraulic monoshock absorber
Rear suspension: Engine-transmission case serving as swingarm, dual action monoshock absorber
Front brake: Hydraulically operated 200 Ø mm stainless steel disc
Rear brake: Mechanically operated 150 Ø mm drum
Front tyre: 3.50” - 10”
Rear tyre: 3.50” - 10”
Length: 1,780 mm
Width: 745 mm
Wheelbase: 1,250 mm
Seat height: 805 mm
Fuel tank capacity: 8 litres
Emissions compliance: Complies with Euro 3 Standards
